Aura Electric - convector with fan
Convector with fan and duralumin grid, finished floor-mounted
The Aura Electric free-standing convector is equipped with axial fans and is therefore ideal for low temperature gradients (e.g. heat pumps). Thanks to its low construction height (280 mm including the support legs), the convector can be integrated into any room with large glazed surfaces. It is ideal for office buildings, conservatories or houses with a lowered sill. The convector is 186 mm wide.
Heat exchangers are made from copper and aluminium, quickly react to the temperature requirements of the room and completely compensate for unpleasant cold penetration from the window. The sheathing is not directly heated by the heating water and thus effectively prevents energy loss through radiation against glazed surfaces (unlike conventional panel heaters), therefore reducing operating costs.
This convector is designed to be mounted on the finished floor. If you are interested in a different color, do not hesitate to contact us.
Standard colours:
The standard colours (RAL 9005, RAL 7016, RAL 9006, RAL 9010 and RAL 9016) are available at no extra charge. Please specify your chosen colour in the order notes when placing your order.
Other colors on request, including non-traditional color decors.
Standard free-standing Aura Electric convector delivery includes:
- longitudinal duralumin grid
- convector sheating
- axial fans
- varnished Cu/Al heat exchanger ending with two pipes with internal thread G 1/2′′
- automatic air-vent valve
- brackets for mounting on the finished floor
- connection cover 2pcs
Optional delivery includes:
- varnishing of sheathing and other components in a different RAL color
- sheathing made from stainless steel sheet
- power supply 24 V DC
- room thermostat Siemens RAB21-DC or Siemens RDG260T
- axial thermostatic valve and shut-off valve
- manual thermostatic head or thermo-electric actuator
